Configuring endpoints

In Step 1 the canvas was empty because nothing was serving it data. Here you'll point the editor at a backend — and run a real one — so it can load nodes into the sidebar and save your work. This is the step that turns a blank canvas into a working editor.

Why endpoints matter

FlowDrop is a frontend editor that talks to a backend API for things like:

• Loading available node types and categories
• Saving and loading workflows
• Executing workflows and pipelines
• Managing playground sessions

Without an endpoint configuration, the editor can render a canvas, but it can't load nodes into the sidebar or persist any data. This is why Step 1 showed an empty canvas — there was no API to fetch nodes from.

The createEndpointConfig helper

FlowDrop provides a helper that generates a full endpoint configuration from a single base URL:

import { mountFlowDropApp } from '@flowdrop/flowdrop/editor';
import { createEndpointConfig } from '@flowdrop/flowdrop/core';
import '@flowdrop/flowdrop/styles';

const app = await mountFlowDropApp(document.getElementById('editor'), {
  endpointConfig: createEndpointConfig('/api/flowdrop'),
  height: '100vh'
});

The createEndpointConfig('/api/flowdrop') call sets up paths for all API operations under that base URL.

It also configures sensible defaults: a 30-second timeout and automatic retries with exponential backoff.

Run a backend

A config that points at nothing won't load nodes or save anything. The fastest way to get a real endpoint is the reference Express server that ships with FlowDrop (apps/example-server-express in the repo). It implements the full API — nodes, categories, port config, and workflow CRUD — backed by in-memory demo data, so you have something live to develop against in seconds:

cd apps/example-server-express
pnpm install
pnpm dev

It starts on http://localhost:7104 and serves the API under http://localhost:7104/api/flowdrop. Open that root URL in a browser to see every endpoint it exposes.

Point the editor at it

Your editor (say, Vite's http://localhost:5173) and the API (http://localhost:7104) are different origins. The cleanest fix — and the one that mirrors production, where the two are usually same-origin — is a dev proxy, so the relative /api/flowdrop from createEndpointConfig just works:

import { defineConfig } from 'vite';
import { svelte } from '@sveltejs/vite-plugin-svelte';

export default defineConfig({
  plugins: [svelte()],
  build: { target: 'es2022' },
  server: {
    // Forward API calls to the example server.
    proxy: { '/api': 'http://localhost:7104' }
  }
});

With both servers running, reload the editor — the sidebar now fills with the node types served by your backend. The endpoint is live, and Save persists to it.

createEndpointConfig('http://localhost:7104/api/flowdrop')

Customizing endpoints

You can override individual settings by passing a second argument:

const endpointConfig = createEndpointConfig('/api/v2/flowdrop', {
  timeout: 60000,
  retry: {
    enabled: true,
    maxAttempts: 5,
    delay: 2000,
    backoff: 'exponential'
  }
});

What's next

Now that the editor knows where the API lives, it's time to define your first node and see it appear in the sidebar.

Tutorial — Step 2 of 5

← Embedding the editor · Next: Your first node →
